Menus accessed via the headphones have the same range of settings as
the remote control:
Press to access the dierent menus
DISC Discrimination: 0-99 (pg 09).
Adjusts with
A ashing digit represents a digit after the decimal point.
SENS Sensitivity: 0-99 (pg10).
Adjusts with
GND Ground balance (pg 17).
0-30: (beach, wet zone) / 60-95: (inland ground)
Adjusts with
FREQ Choice of frequency used: 4, 8, 12, 18kHz (pg 11).
Change with
TONE Choice of number of tones: 2, 3, 4 tons, P1(PITCH) (pg 36).
Change with
VOL Adjusts sound volume in headphones: 0-9
Adjusts with
COIL Choice of coil used when several are available.
The coils are numbered according to the order in which they were entered:
01 = Original coil
02= Optional coil 1
03= Optional coil 2, etc.
DISC
SENS
GND
FREQ
TONE
VOL
COIL
29
