POWER SUPPLY-batteries
The search coil, remote control and headphones are all powered by identical
lithium polymer batteries. These miniature, high-capacity batteries can be
recharged quickly. The dierent Dēus elements can be charged while switched
on or o, but switching them o speeds up the process.
You should use the power adaptor supplied, which enables all three elements
to be charged simultaneously when used with the USB/3 mini-B cable, also
supplied.
Connect the USB plug to the power adaptor
connect the mini-B plugs to the remote control, headphones and to the
charging clamp.
OPTION
MENU
1 - BASIC 1
DISC
SENS
GND
TONE
VOL
COIL
FREQ
The search coil is charged via the connection clamp supplied, which is connected to the coil
according to the grooves in the coil cover.
You will see that the clamp is shaped in such a way to prevent it being connected the wrong way
round.
Correct
Incorrect
Ensure that the clamp is the right way round before connecting it to the coil
33
