dS1242 User Manual v4.10
A quick look
Ethernet connected module, 10/100Mb auto negotiated.
Relays – 2 x 16Amp 250Vac C/O.
I/O – 4 x digital I/O's NPN output, Volt free input.
2 x 10-bit analogue input
Power – 12VDC 500mA supply required. 2.1mm center positive.
Connections – Screw Terminals for N/O N/C and Common contacts
PCB size – 82mm x 84mm
Controlled graphically by secure webpage or optionally one of ASCII, Binary or Modbus com-
mand sets over TCP/IP.
Email notifications – 8 selectable notifications, up to 100 emails/hour max.
Peer to Peer – Control relays on other modules.
Schedules – Able to schedule events based on time of day/week
Counter/Timers – Count or time events. 20 counts/second Max.
Also available when optionally programming in dScript is a TTL level serial port.
