dS1242 User Manual v4.10

Introduction

The dS1242 is an Ethernet connected relay module featuring 2 channels of 16Amp 250Vac re-

lays. Each relay has both normally open (NO) and normally closed (NC) as well as the common

available on three terminals.

In addition to the relays, the dS1242 has 4 digital I/O channels and 2 x 10-bit analogue input

channels (0v-3.3v input range).

The dS1242 requires a 12v power supply capable of supplying a minimum of 500mA such as

this one:

http://www.robot-electronics.co.uk/universal-12vdc.html

The dS1242 has four built in control methods.

Primary control method is graphically by using its built in secure website.

Secondary control may be one of:

ASCII - type in commands via a program such as PuTTY.

Binary - Command set using binary codes

Modbus – Functions 1, 4, 5 and 15 supported

And if you should wish to modify the supplied firmware – you can.

Behind the scenes there is dScript, a powerful multi-threaded operating system and program-

ming language. The supplied firmware is written in dScript as well as HTML, CSS and

Javascript on the webpages and the full source is in the separately downloadable dScript sup-

port package.

You do not need to use dScript at all, but its great to know its there - just in case you do.
