27
A-DV56
EN
specificAtions
Storage & Transportation Humidity Range.............. 0% to 95% RH non-condensing
Maximum Limited Pressure ............................30 cmH
2
O under normal use
Sound Level (tested per ISO 17510) ...................................... 26 dBA
Filter Specifications
Standard Filter > 3.0 micron particles
Optional Fine Particle Filter > 0.3 micron particles
Max Flow Rates
154 L/m @ 8.5 cmH
2
O (1/3 max pressure)
180 L/m @ 16.5 cmH
2
O (2/3 max pressure)
181 L/m @ 25 cmH
2
O (max pressure)
Pressure Accuracy ..............................................................................................± 1.0 cmH
2
O
Pressure Swings
(cmH
2
O peak to peak at 500mL tidal volume, sine wave profile)
Breaths per minute 10 15 20
@ 8 cmH
2
O
0.5 0.5 0.5
@ 10 cmH
2
O
1.0 1.0 1.0
@ 17 cmH
2
O
1.0 1.0 1.0
@ 25 cmH
2
O
1.0 1.0 1.0
Warranty .......................................................................................................Three-year limited
Equipment classification with respect to protection from electric shock...................... Class II
Degree of protection from electric shock ...............................................Type BF Applied Part
Degree of protection against ingress of liquids ..................................................................IPX1
Equipment not suitable for use in the presence of a flammable anesthetic mixture with air
or with oxygen or nitrous oxide.
Mode of operation .................................................................................................. Continuous
Clinical Specifications for Digital Outputs
Mask Pressure ..........................................0 to 25.5 cmH2O ± 0.5
Patient Flow .....................................-127 to +127 L/min ± 10 L/min
Leak Flow..........................................0 to +127 L/min ± 10 L/min
Tidal Volume ....................................0 to 1023 mL ± 30% of reading
