aDVancED mEnu controlS
DV53 Standard Plus Patient Menu Layout
The following chart shows by Mode each Display you will scroll through using the Next or
Previous buttons on the keypad. Pressing the Down key at the Enable Menu Display will
allow you to enter this submenu - then use Next or Previous buttons to scroll through it;
press the Up button to return to main menu. Once the final Display is reached, pressing the
Next button will return you to the first Display.
UP () BUTTON
RIGHT () LEFT () BUTTONS
Auto-ON 
Enabled
Auto-OFF 
Disabled
Exit Menu
Press 
Mask Fit Check
Enabled
Low Backlight
Enabled
MENU - CPAP Mode
 There are 5 levels of SmartCode data. Use UP
 or DOWN  key to change between levels.
RIGHT () LEFT () BUTTONS
SmartFlex Mode 
Full Time
SmartFlex 
3
Exit Menu
Press 
SmartFlex IRnd 
3
SmartFlex ERnd 
3
DOWN () BUTTON
P:10.0 FLX CPAP
Heat:Off
Set Pressure
10.0 cmH2O
Delay Pressure
4.0 cmH2O
Delay Time 
20 minutes
Enable Menu
Press 
SmartCode 1-Day
F6CD-37F-357R
Tubing Length 
1.8 m (6 ft)
SmartFlex Menu
Press 
UP () BUTTON
Compliance Meter
123456.7 hours
Serial Number
HD000005
Firmware Version
V0.20 30/06/2010
LCD Contrast Adj
50 %
Adherence Score
83% (25/30)
DOWN () BUTTON
Heater setting shown if DV5HH is attached, FLX
shown if SmartFlex feature is turned on.
