30
SE-DV53-1
EN
SpEcificationS
Filter Specifications
Standard Filter > 3.0 micron particles
Optional Fine Particle Filter > 0.3 micron particles
Maximum Flowrate (per ISO 17510-1:2007)
Test Pressures
3.0 cmH20 7.0 cmH20 12.0 cmH20 16.0 cmH20 20.0 cmH20
Measured
pressure at the
patient connection
port (cmH20)
2.9 6.4 11.0 15.0 19.0
Average flow at
the patient
connection port
(l/min)
83.8 126.8 137.4 130.0 113.8
Long Term Static Pressure Accuracy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . +/- 0.5 cmH2O
Dynamic Short-Term Pressure Accuracy with and without
DV5HH Humidifier
(per ISO 17510-1:2007)
Waveform
Volume
[mL]
Breath Rate
[min-1]
Set Pressure
[cmH2O]
Pressure Accuracy
[Pk-Pk cmH2O]
Sinusoidal cycle with
I:E = 1:1
500 10, 15, 20
3.0 0.5
7.0 0.5
12.0 1.0
16.0 1.0
20.0 1.0
Equipment classification with respect to protection from electric shock . . . . . . . . . . .Class II
Degree of protection from electric shock . . . . . . . . . . . . . . . . . . . . . . . Type BF Applied Part
Degree of protection against ingress of liquids . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . IPX1
Equipment not suitable for use in the presence of a flammable anesthetic mixture with air
or with oxygen or nitrous oxide.
Mode of operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Continuous
