Chapter 3
www.dfi .com
33
Chapter 3 BIOS Setup
SIO NUVOTON6106D
This section configures the system super I/O chip parameters.
Enable/Disable Smart Fan.
SIO NUVOTON6106D

Smart Fan Control
Serial Port 1
Serial Port 2
Serial Port 3
WDT
Case Open

Hardware Monitor
Advanced
F1 Help ↑↓ Select Item F5/F6 Change Values F9 Setup Defaults
Esc Exit ←→ Select Menu Enter Select

SubMenu F10 Save and Exit
InsydeH20 Setup Utility Rev. 5.0
<Auto>
<Auto>
<Auto>
<Disable>
<Disable>
Serial Port 1 to Serial Port 3
Configure the settings to use the serial port.
Disable No configuration
Enable User confi guration
Auto EFI/OS chooses confi guration
Case Open
Enable or disable the case open.
System Smart Fan Control
Enable or disable the system smart fan.
Boundary 1 to Boundary 4
Set the boundary temperature. The range is from 0-127
o
C.
Fan Speed Count 1 to Fan Speed Count 4
Set the fan speed. The range is from 0-100%.
Smart Fan Control
This field enables or disables the smart fan control.
System Smart Fan Control
System Fan Mode
Boundary 1
Boundary 2
Boundary 3
Boundary 4
Fan Speed Count 1
Fan Speed Count 2
Fan Speed Count 3
Fan Speed Count 4
Advanced
F1 Help ↑↓ Select Item F5/F6 Change Values F9 Setup Defaults
Esc Exit ←→ Select Menu Enter Select

SubMenu F10 Save and Exit
InsydeH20 Setup Utility Rev. 5.0
<Enable>
<SMART FAN IV>
[30]
[40]
[50]
[60]
[20]
[30]
[50]
[75]
Enable System Smart Fan.
