Hardware Installation
RJ45 LAN Port
The system board is equipped with an onboard RJ45 LAN port at
location CN4. LAN allows the system board to connect to a local
area network by means of a network hub.
BIOS Setting
Configure the onboard LAN in the Integrated Peripherals submenu
of the BIOS. Refer to chapter 3 for more information.
Driver Installation
Install “NVIDIA Windows nForce Drivers”. Refer to chapter 4 for
more information.
W
LAN
