Hardware Installation
Bandwidth
x1
x8
x1
x8
The PCI Express Slots
The illustration below shows the bandwidth of the PCI Express slots.
x1 PCI Express slot
X
x16 PCI Express slot
x1 PCI Express slot
x16 PCI Express slot
