DV 20 E AFM General
Doc. No. 4.01.25-E Rev. 2 22-Mar-2022 Page 1 - 5
Wing Flaps
Area (total, left + right) : 2.16 m² 23.25 sq.ft.
Horizontal Tail
Area : 1.83 m
2
18.7 sq.ft.
Elevator area : 0.50 m² 5.4 sq.ft.
Angle of incidence : -4° relative to longitudinal axis of airplane
Landing Gear
Track : 1.86 m (6 ft 1 in)
Wheelbase : 1.68 m (5 ft 6 in)
Nose wheel : 5.00-4*
Main wheel : 5.0-5*
* for details refer to the Airplane Maintenance
Manual, Doc. No. 4.02.25, latest revision
