Diamond Aircraft DV 20 E - Dimensions

General DV 20 E AFM
Page 1 - 4 Rev. 2 22-Mar-2022 Doc. No. 4.01.25-E
1.4 DIMENSIONS
NOTE
All dimensions shown below are approximate.
Overall Dimensions
Span : 10.87 m 35 ft 8 in
Length : 7.15 m 23 ft 5 in
Height : 2.10 m 6 ft 11 in
Wing
Airfoil : Wortmann FX 63-137/20 HOAC
Wing Area : 11.60 m² 125 sq.ft.
Mean aerodynamic chord : 1.09 m 3 ft 7 in
Aspect ratio : 10.0
Dihedral : 4°
Leading edge sweep : 0.5°
Aileron
Area (total, left + right) : 0.65 m² 7 sq.ft.
