Diamond TX Series - Specifications

Transmitters 9 November 2001 125
Next Chapter
Tran sm it te r
Specifications
200-TX Series Optical Transmitters
Notes:
a. When used with a 2RRX.
b. Depth includes shield.
Notes 200-TX Units
Bandwidth 5–200 MHz
Optical Wavelength (all series) 1310 (± 10) nm
Optical Output Power (all series)
210-TX 6 (± 0.25) dBm
212-TX 8 (± 0.25) dBm
214-TX 10 (± 0.50) dBm
Safety Power Shutdown (all series) Yes
RF Input Level, Main (20 channels) 18 (± 0.1 dB) dBmV
RF Input Level, Auxiliary(± 0.5 dB) –10 dBmV
Isolation, Auxiliary to Main Input –10 dBc
Auxiliary Input Bandwidth (all series) 5-200 MHz
AGC—Input Range (all series) ± 3dB
Response Flatness (all series) a ± 0.75 dB
Response Slope (all series) 0 to +0.5 dB
Input Impedance (all series) 75 ohms
Input Return Loss:
5–200 MHz (all series) 16 dB
RF Test Point (± 1.0 dB) (all series) –20 dB
Carrier-to-Noise Ratio
(20 NTSC channels) See AM Optical Performance table.
Composite Second Order
(20 NTSC channels) See AM Optical Performance table.
Composite Triple Beat
(20 NTSC channels) See AM Optical Performance table.
Optical Connector FC/APC, SC/APC
RF Connector F-Type
Dimensions (all series)
(height x width x depth) b 4.75 x 1.81 x 16.25
(12.1 x 4.6 x 41.3)
in.
(cm)
Weight (all series) 3.5
(1.6)
lb.
(kg)
Power Consumption (all series) (maximum) 25 W
Powering (all series,
± 0.5 V) +24, +5, –5VDC
Ambient Temperature (all series)
See “Diamond Transport Operating Temperature
Range.”
Thermal Shutdown for Laser 75
(167)
°C
(°F)
All specifications are subject to change without notice.
