Diamond Transport transmitters are available in several
models. Use the following key to interpret model names.
To support local video injection, the 800E-TX and 800G-TX
transmitter series offer higher isolation between the auxiliary
and main inputs than the 800C-TX series offers. When
combined with the DT-SRS sub-rack splitter, the combined
isolation (between transmitters) of the locally injected
channels is ≥ 60 dB. In addition, the 800E-TX and 800G-TX
transmitter series provides three AGC options (Customer-set
level, Factory-set level, and Manual [i.e., AGC off]) while the
800C-TX offers only Factory-set and Manual settings.
DT- _ _ _ _-TX- _____
Diamond Transport System
Highest Forward Frequency
2 = 200 MHz (return)
7 = 750 MHz (forward)
8 = 862 MHz (forward)
Optical Connector Options
FC/APC = FC/APC
SC/APC = SC/APC
E2000D = E2000
Optical Link Budget (dB)*
10, 12, or 14 dB (200-TX models)
05 to 15 dB (700-TX & 800-TX models)
Isolation and/or Optimization Options
Blank = Optimized for 550 MHz Analog (700-TX only)
Blank = Standard isolation (200-TX only)
C = Optimized for 862 MHz Analog (800C-TX only)
E = Optimized for 650 MHz Analog, High Isolation
Auxiliary RF Input (800E-TX only)
G = Optimized for 862 MHz Analog, High Isolation
Auxiliary RF Input (800G-TX only)
