DIMENSIONS & MODELS
ATLANTIC
00-ATL
ADRIATIC
00-ADR
PACIFIC
00-PAC
BERING
00-BER
BRISTOL
00-BRI
overall
W: 21.00”
H: 19.25”
D: 18.25”
Flue ⌀ :
Burner ⌀ :
BTU:
Valve cal.:
Coil options:
Fan control:
oven
W: 9.00”
H: 8.00”
D: 11.00”
overall
W: 23.25”
H: 23.50”
D: 16.25”
Flue ⌀ :
Burner ⌀ :
BTU:
Valve cal.:
Coil options:
Fan control:
oven
W: 10.50”
H: 10.50”
D: 12.75”
overall
W: 21.75”
H: 23.50”
D: 21.50”
Flue ⌀ :
Burner ⌀ :
BTU:
Valve cal.:
Coil options:
Fan control:
oven
W: 10.00”
H: 10.50”
D: 13.00”
overall
W: 26.25”
H: 23.50”
D: 21.50”
Flue ⌀ :
Burner ⌀ :
BTU:
Valve cal.:
Coil options:
Fan control:
oven
W: 15.00”
H: 10.50”
D: 13.00”
overall
W: 30.50”
H: 28.75”
D: 23.00”
Flue ⌀ :
Burner ⌀ :
Max BTU:
Valve cal.:
Coil options:
Fan control:
oven
W: 16.00”
H: 12.00”
D: 14.50”
5”
7”
24,375
4D
1 & 2 turn
Built-in
5”
6”
16,250
3D
1 & 2 turn
Built-in
5”
6”
16,250
3D
1 & 2 turn
Built-in
5”
6”
16,250
3D
1 & 2 turn
External
4”
6”
16,250
3D
1 turn only
External
9
85
lbs
95
lbs
125
lbs
135
lbs
190
lbs
FIG 2
FIG 3
FIG 4
FIG 5
FIG 6
