Dickinson Pacific - Not Producing Enough Heat; Inconsistent Fuel Flow

47
NOT PRODUCING ENOUGH HEAT
Investigate
Diagnose
Correct
Appliance not
producing
enough heat
does the space it is
installed in exceed the
square footage the
appliance is able to
heat?
CAUTION: ALWAYS FOLLOW THE MANUFACTURER’S LIGHTING INSTRUCTIONS FOR THIS
APPLIANCE FOUND ON PAGE 35. FAILURE TO ADHERE TO SAFE RECOMMENDED LIGHTING
PROCEDURES CAN RESULT IN INJURY, DAMAGE TO PROPERTY OR EVEN DEATH.
!
Fuel flow is
inconsistent
Is the color &
appearance of
the flames
consistent and
steady?
INCONSISTENT FUEL FLOW
Could the presence of
window panes,
uninsulated bulkheads
or degraded insulation
be causing excessive
heat loss?
Has the appliance been
operated for long
enough to raise heat in
the cabin?
It takes time to bring a natural
draft appliance up to
operating temperatures. In
extremely cold conditions the
time needed to bring an
appliance up to operating
temperatures will be
increased
See page 16
Yes, at least 1-2 hours
No
No
Does the chimney have
less than 4 continuous
vertical feet of rise?
Does it have elbows?
Non-conforming
installs may weaken
the draft and reduce
heat output.
See pages 20-21
No
Yes?
Are flames burning
inside the burner pot?
and/or
Yes?
Are flames
predominantly blue?
Are flames
predominantly orange?
Reduce air to burner by;
• Opening barometric
damper
• Turning on fan
See page 38
Reduce fuel input. Turn
off fan air / close
barometric damper to
help flames raise above
burner ring.
See page 38
Yes
Are you supplying
fuel from a pump?
Calibrate fuel flow
See page 43
No
Yes
Is the pump
pulsing/ticking
consistently?
Make sure the
pump is not
delivering fuel at
pressure greater
than 3 psi
See page 44 for
pump priming &
setting
Check fuel lines
leading to pump
for air leaks
See page 44
Is fuel exiting the
valve’s overflow
fitting?
Clean the valve
needle & seat
See page 43
Yes
No
Yes
Yes
No
Please note:
Any sign of fuel overflow,
inconsistency or flooding must be
corrected by disassembling and
cleaning the needle & seat of the
metering valve. See a video
demonstration of this and other
steps on the Dickinson Marine
YouTube channel.
Yes
No
Yes
