SAFETY CLEARANCES
10
TWO INCH MIN. CLEARANCE TO PROTECTED SURFACE
TWO INCH MIN. CLEARANCE TO PROTECTED SURFACE
TWO INCH MIN. CLEARANCE TO PROTECTED SURFACE BEHIND
3 FOOT MIN. CLEARANCE ABOVE STOVETOP
Bulkhead
Insulation
board
Ceramic
tile
Bulkhead
Insulation
board
Half Inch
Air gap
Steel
plate
Examples of protected surfaces
VIEW FROM TOP
FIG 7
FIG 8
FIG 9
FIG 10
