Digikeijs DR5000 User Manual

DR5000 DIGICENTRAL
P 7
www.digikeijs.com
1 LAN connecon (100 MBit)
2 S88-N connecon
3 LocoNet® B connecon (LocoNet boosters)
4 LocoNet® T connecon (LocoNet equipment)
5 Track output
6 Feedback bus (X –Bus® & R-Bus®)
7 Booster Bus (B-Bus®)
8 RS-Bus®
9 Programming track
10 USB connecon
11 Power input connecon
12 Track acvity
13 USB acvity
14 Infrared receiver
15 XpressNet® acvity
16 STOP buon (no track voltage)
17 START buon (track voltage on)
18 LocoNet® acvity
19 S88-N acvity
20 Wi-Fi acvity
21 LAN acvity
22 Router acvity
1
2 3 4 5 6 7
8
9
10
11
12
13 14 15 16 17 18 19 20 21 22
2.3 Hardware overview
® R-Bus, B-Bus are trademarks which are registered in the name of Modelleisenbahn GmbH. XpressNet and RS-Bus is a trademark registered in the name of Lenz

Digikeijs DR5000 Specifications

General

Manufacturer	Digikeijs
Category	Controller
Programming Track Output	Yes
Interface	Ethernet, USB
Protocols	DCC
Connectivity	USB, LAN
Operating Temperature	0°C to 40°C
Storage Temperature	-20°C to 70°C
