Digikeijs DR5013 DIGIREVERSE User Manual

DR5013 DIGIREVERSE
P 27
www.digikeijs.com
® R-Bus, B-Bus are trademarks which are registered in the name of Modelleisenbahn GmbH. XpressNet and RS-Bus is a trademark registered in the name of Lenz
Stand 2021-07-06
5.3 Connecon DR5013 with sensor tracks (S0,S1,S2,S3) and LocoNet®
This connecon example shows the use of the DR5013 in conjuncon with sensor tracks (S0,S1,S2,S3). With this connecon, the DR5013 automacally reverses the polarity (short-
circuit-free) and may be able to switch the entry/exit switch automacally on exit. LocoNet® transmits various informaon (Railcom® informaon, feedback, short-circuit message,
etc.) to the control centre and can be evaluated accordingly.
Funconality:
The turnout is e.g. bent: The locomove reaches the entry detector S0. The DR5013 now knows the posion of the locomove and thus the direcon in which it enters the revers-
ing loop. The DR5013 switches the polarity of the reversing loop in such a way that the polarity matches the entry. Next, sensor track 1 (S1) is approached. S1 triggers only a busy
signal via LocoNet® with the integrated occupancy detector (the polarity of the KS has already been switched from S0). If the locomove reaches the area of the reversing loop
track, this is reported as occupied to the central staon via LocoNet® with the integrated occupancy detector and can be evaluated, for example, with a control program. At the
same me, the Railcom® data of the locomove (address, QoS messages, etc.) are read out in the enre reversing loop track (S1,S2,Track) and also reported to the central staon.
The locomove reaches sensor track 2 (S2). The DR5013 now recognizes that the locomove is on its way to the exit of the reversing loop. The polarity of the reversing loop is
switched according to the polarity of the exit. In addion, the DR5013 can "correct" the turnout at this moment so that a smooth exit is possible. If the turnout is in a straight line,
the sequence is the same except that the order of the sensor tracks is dierent (S3,S2 -> S1).
Terminal assignment:
S0 Entrance to Sensor track 1
S1 Sensor track 1
S2 Sensor track 2
S3 Entrance to sensor track 2
Track reversing track
Necessary track separaon
Here we describe which sengs are to be made in the DR5013 cong
tool.
Sensor track sengs:
In the input elds of the sensor tracks S0, S1, S2, S3,Track (T) the feedback con-
tacts must be entered which are to be used for the respecve sensor tracks. The
feedback numbers for S1,S2 and Track (T) are assigned directly in the DR5013.
For the sensor tracks S0 and S3 the feedback numbers must be entered by the
DR4088LN-CS which are dened there.
Turnout mode:
In this example, the sengs set should be used for the switch mode. The mag-
nec arcle address of the turnout must be entered.
Turnout status:
Both sengs are possible for the basic posion of the turnout.
