Digital Projection E-Vision Laser 7500 & 8500 Series
Reference Guide
APPENDIX B: SUPPORTED SIGNAL INPUT MODES
Rev B September 2016
Standard
Resolution
Horizontal
Frequency (kHz)
Frame Rate (Hz)
PCLK (MHz)
Component /
5BNC
VGA - RGBHV
5BNC - RGBHV
DisplayPort /
DVI-D
HDMI / HD-BaseT
HD/SDI/3G
Remark
RGB
YUV 8-bit
YUV 10-bit YUV 12-bit
PC
(continued)
1440 x 900 55.935 60 106.500 X X X X VESA DMT
1280 x 768 47.776 60 79.500 X X X X VESA DMT
1280 x 800 49.702 60 83.500 X X X X VESA DMT
1280 x 960 60.000 60 108.000 X X X X VESA DMT
Apple Mac 640x480 35.000 66.67 30.240 X X X X Apple MAC
832x624 49.720 74.54 57.280 X X X X Apple MAC
SDTV 480i 15.734 59.94 13.500 X X
1440x480i 31.468 60 27.000 X X X X
1440x576i 31.250 50 27.000 X X X X
576i 15.625 50 13.500 X X
EDTV 480p 31.469 59.94 27.000 X X X X X X X X
576p 31.250 50 27.000 X X X X X X X X
HDTV 1035i 33.750 60 74.250 X X X X X X X X X
1080i 28.125 50 74.250 X X X X X X X X X
1080i 33.716 59.94 74.176 X X X X X X X X X
1080i 33.750 60 74.250 X X X X X X X X X
720p 37.500 50 74.250 X X X X X X X X X
720p 44.955 59.94 74.176 X X X X X X X X X
720p 45.000 60 74.250 X X X X X X X X X
1080p 26.973 23.98 74.176 X X X X X X X X X
1080p 27.000 24 74.250 X X X X X X X X X
1080p 28.125 25 74.250 X X X X X X X X X
1080p 33.716 29.97 74.176 X X X X X X X X x
1080p 33.750 30 74.250 X X X X X X X X X
1080p 56.250 50 148.500 X X X X X X X X X
Notes
