Digital Projection E-Vision Laser 7500 & 8500 Series
Reference Guide
APPENDIX B: SUPPORTED SIGNAL INPUT MODES
Rev B September 2016
Appendix B: Supported Signal Input Modes
2D formats
Standard
Resolution
Horizontal
Frequency (kHz)
Frame Rate (Hz)
PCLK (MHz)
Component /
5BNC
VGA - RGBHV
5BNC - RGBHV
DisplayPort /
DVI-D
HDMI / HD-BaseT
HD/SDI/3G
Remark
RGB
YUV 8-bit
YUV 10-bit YUV 12-bit
PC 640x480 31.469 59.94 25.175 X X X X VESA DMT
640x480 37.500 74.99 31.500 X X X X VESA DMT
640x480 43.269 85 36.000 X X X X VESA DMT
800x600 37.879 60.32 40.000 X X X X VESA DMT
800x600 46.875 75 49.500 X X X X VESA DMT
800x600 53.674 85.06 56.250 X X X X VESA DMT
848x480 23.674 47.95 25.000 X X X X VESA CVT
848x480 31.020 60 33.750 X X X X VESA DMT
1024*768 48.363 60 65.000 X X X X VESA DMT
1024*768 60.023 75 78.750 X X X X VESA DMT
1024*768 68.677 85 94.500 X X X X VESA DMT
1280x720 35.531 47.95 57.987 X X X X VESA GTF
1280x1024 63.981 60.02 108.000 X X X X VESA DMT
1280x1024 79.976 75.02 135.000 X X X X VESA DMT
1280x1024 91.146 85.02 157.500 X X X X VESA DMT
1600x1200 75.000 60 162.000 X X X X VESA DMT
1920x1080 53.225 47.95 135.403 X X X X VESA CVT
1680x1050 65.290 60 146.250 X X X X VESA DMT
1920x1200 RB 61.816 50 158.250 X X X X VESA CVT
1920x1200 RB 74.038 60 154.000 X X X X VESA CVT
1400X1050 65.317 60 121.750 X X X X VESA DMT
1366 x 768 47.712 60 85.500 X X X X VESA DMT
