Specifications
A/D Converter: 24 bit
D/A Converter: 24 bit
Sample Rate: 44.1 kHz.
DSP Section:
Architecture: Static-Dynamic Instruction Set Computer (S-DISC™)
Digital Signal Path Width: 24 bits (144.5 dB)
Internal Data Path Width: 48 bits (289 dB)
Dynamic Delay Memory: 256k x 24 bits (3.5 seconds)
Static Delay Memory: 256 24-bit registers (6.55 milliseconds)
Data ALU Processing: 11.3 MIPS
Address ALU Processing: 16.9 MIPS
Multiplier Size: 24 bits x 24 bits
Tube Type:
(1) 12AX7
Input Section:
Connector: 1/4” Unbalanced TRS
Nominal Level: -8 dBu
Maximum Level: +10 dBu
Impedance: 470 kohms
Jam-A-Long: 1/8” Stereo TRS
Output Section:
Connector: 1/4” TRS
Nominal Level: +4 dBu
Maximum Level: +18 dBu
Impedance: 50 ohms
Headphone: 1/8” Stereo TRS
S/PDIF: RCA
General:
S/N ratio: Greater than 97 dB (A-weighted); ref = max signal, 22 kHz measurement bandwidth
Total Harmonic Distortion: Less than 0.005% (1 kHz.); ref = 1 dBu with unity gain
Memory Capacity: Factory: 50 Programs User: 50 Programs
Power Requirements (PS0920 Power Ratings):
Power Input (from outlet) Power Output (to RP14D)
US and Canada: 120 V AC, 60 Hz, 34 Watts 9 VAC @ 2.1 Amps
Japan: 100 V AC, 50/60 Hz 9 VAC @ 2.1 Amps
Europe: 230 V AC, 50 Hz, 35 Watts 9 VAC @ 3 Amps
UK: 240 V AC, 50 Hz, 28 Watts 9 VAC @ 2.2 Amps
Power Consumption: 18.9 Watts
Dimensions: 24.25” (L )x 8.5” (D) x 2.75”(H)
Weight: 7.1 lbs.
RP14 UserÕs Guide Section Five - Appendix
28
