32
USING AN FS3X FOOTSWITCH
An optional DigiTech FS3X
Footswitch can be connected
to the CONTROL IN jack for
additional hands-free control.
A TRS (tip-ring-sleeve) 1/4”
cable must be used when
connecting the FS3X to the
TRIO+.
When using an optional FS3X
Footswitch for control, there
are 3 modes of operation to
select from. The table below
shows the 3 modes and the
functions controlled by each
of the FS3X footswitches in
each mode.
TRS Cable
Footswitch
Footswitch
FS3X
Mode
Press & Hold
While Connecting
FS3X Control
Footswitch 1 Footswitch 2 Footswitch 3
Live
(Default)
FS3X Footswitch 1
Go to next STYLE
(hold to go to
previous STYLE)
Go to next PART (hold
when stopped to turn
on drum stick count-in
or metronome)
Toggle ALT TIME
mode
Table Top FS3X Footswitch 2
Same as TRIO+
LOOPER footswitch
Go to next PART (hold
when stopped to turn
on drum stick count-in
or metronome)
Same as TRIO+
BAND footswitch
Live Mixer FS3X Footswitch 3 Hold to mute bass Hold to mute drums
Hold to mute bass
and drums
To change the FS3X mode:
1. Ensure the TRIO+ is powered up and running.
2. Unplug the FS3X from the TRIO+ (if it is currently plugged in).
3. Press and hold the FS3X FOOTSWITCH corresponding to the desired mode (see table above).
4. While holding the FOOTSWITCH, plug the FS3X into the CONTROL IN jack. Keep holding the
FOOTSWITCH down for at least 1 second after plugging in the FS3X before releasing it.
5. The TRIO+ will now use the new footswitch mode.
