Dimplex DF2608 Service Manual

4
Maintenance
WARNING: Disconnect power before attempting any
maintenance or cleaning to reduce the risk of re, electric
shock or damage to persons.
Light Bulb Replacement
Allow at least ve (5) minutes for the light bulbs to cool
before touching them to avoid accidental burning of the skin.
The light bulbs need to be replaced when you notice a dark
section of the ame or when the clarity and detail of the
log ember bed exterior reduces. There are three (3) bulbs
under the Log Set Assembly, which generate the ames
and embers, and two (2) bulbs above that illuminate the log
exterior.
Lower Light Bulb Requirements: Quantity of three (3) clear
chandelier or candelabra bulbs with an E-12 (small) socket
base, 60 Watt rating. Example: GE 60BC or Philips 60CTC.
Do not exceed 60 Watts per bulb.
Helpful Hints: It is a good idea to replace all light bulbs at
one time if they are close to the end of their rated life. Group
replacement will reduce the number of times you need to
open the unit to replace light bulbs. Care must be taken
when removing the Log set assembly as it contains LED’s
and wires (DF2608 only).
Slide replace out of mantel.1.
Lay unit on it’s back for safe removal of front glass.2.
Remove three (3) Phillips screws from the right side of 3.
trim.
Remove trim.4.
Slide glass to right side of replace to remove (Figure 3).5.
Pull the front edge of the plastic ember bed or plastic 6.
grate up and forward until the rear tab releases from
the ledge located at the bottom of the partially reective
glass (Figure 4).
!
IMPORTANT: Only handle the log set assembly by the
ember bed or plastic grate.
!
NOTE: Log set assembly ts tightly into rebox, some
force may be necessary to remove.
Set log set assembly in front of replace.7.
Remove icker rod by pulling rod to the right, towards the 8.
icker motor. Bend the icker rod enough to clear the
bracket on the left, lift out and pull icker rod off of icker
motor shaft (Figure 5).
Remove four (4) Phillips screws (two (2) per side) which 9.
attach light lter bracket for easier access to light bulbs
(Figure 5).
Unscrew bulbs counter clockwise to remove.10.
Insert new bulbs and screw in clockwise.11.
Replace light lter bracket and icker rod.12.
Install the log set assembly by placing the front, bottom 13.
edge of the ember bed in the track behind the control
panel. Once in place, push down on the back edge of
the ember bed until the rear tab snaps into place under
the mirror (Figure 4).
!
NOTE: Ensure the log set Assembly is installed tightly
under the bottom edge of the mirror to prevent light leakage.
Lay unit on it’s back and slide Front Glass back into 14.
position and attach trim.
Upper Light Bulb Requirements: Quantity of two (2) clear
chandelier or candelabra bulbs with an E-12 (small) socket
base, 15 Watt rating.
Do not exceed 25 Watts per bulb.
To access the upper light bulb area:
Slide replace out of mantel.1.
Lay unit on it’s back for safe removal of front glass.2.
Remove three (3) Phillips screws from right side of trim.3.
Remove trim.4.
Slide glass to the right side of the replace to remove 5.
(Figure 3).
Upper bulbs are located in the upper left and upper 6.
right corners of replace, behind the light block bracket
(Figure 5).
Remove the four (4) Phillips screws that attach the light 7.
block to the rebox (Figure 5).
Unscrew bulbs counter clockwise.8.
Insert new bulbs and screw in clockwise.9.
Re-attach light block bracket.10.
Lay unit on it’s back, slide front glass back into position 11.
and attach Trim.
Glass Cleaning
The glass is cleaned in the factory during the assembly
operation. During shipment, installation, handling, etc.,
the clear door may collect dust particles, these can be
removed by dusting lightly with a clean dry cloth.
To remove ngerprints or other marks, the clear door can
be cleaned with a damp cloth.
Fireplace Surface Cleaning
Use a cloth dampened with warm water only to clean
painted surfaces of the electric replace. Do not use
abrasive cleaners.
Trim
Front
Glass
Log Set
Assembly
Figure 3
Back
Ledge
Log
Ember Bed
Rear
Tab
Front
Edge
Side Section
Figure 4
Figure 5
Flicker Rod
Light Filter
Bracket screws (2)
Lower Light
Bulbs (3)
Light Block
Light Block screws (4)

Dimplex DF2608 Specifications

General

Type	Built-in fireplace
Flueless	Yes
Fuel type	Electric
Orientation	Vertical
Heating power	1440 W
Product color	Black
Fireplace type	Closed

Weight and Dimensions

Depth	224 mm
Width	695 mm
Height	597 mm
