Dimplex DF2608 Service Manual

9
Front Glass Replacement
CAUTION: If unit was operating prior to servicing allow
at least 10 minutes for lights, heating elements and top
panel to cool off to avoid accidental burning of skin.
WARNING: Disconnect power before attempting any
maintenance to reduce the risk of electric shock or damage
to persons.
Slide rebox out of mantel.1.
Lay unit on it’s back for safe removal of Front Glass.2.
Remove three (3) Phillips screws from right side of Trim.3.
Remove Trim.4.
Slide glass to the right side of the rebox to remove 5.
(Figure 6).
Reassemble using replacement Front Glass in reverse 6.
order as described above.
CAUTION: Even though the glass is safety glass it
may break if bumped, struck or dropped. Care must be
taken when handling the glass.
Reective Glass.
!
IMPORTANT: Only handle the Log Set Assembly by
the Ember Bed or plastic grate.
!
NOTE: Log Set Assembly ts tightly into rebox, some
force may be necessary to remove.
Loosen but do not remove the two (2) Philips screws 7.
that clamp the Partially Reective Glass in place, and
swivel down so that the clamp clears the edge of the
Partially Reective Glass (Figure 7).
Push the Partially Reective Glass out from behind to 8.
clear the frame and remove.
Insert replacement Partially Reective Glass top end 9.
rst and lay the bottom end gently in the bottom track
of the frame.
Tighten clamps back into place and reassemble rebox 10.
in reverse order as described above.
Partially Reective Glass Replacement
CAUTION: If unit was operating prior to servicing allow
at least 10 minutes for lights, heating elements and top
panel to cool off to avoid accidental burning of skin.
WARNING: Disconnect power before attempting any
maintenance to reduce the risk of electric shock or damage
to persons.
Slide rebox out of mantel.1.
Lay unit on it’s back for safe removal of Front Glass.2.
Remove three (3) Phillips screws from the right side of 3.
Trim.
Remove Trim.4.
Slide glass to right side of replace to remove (Figure 5.
6).
CAUTION: Even though the glass is safety glass it
may break if bumped, struck of dropped. Care must be
taken when handling the glass.
Pull the front edge of the plastic Ember Bed or plastic 6.
grate up and forward until the rear tab releases
from the ledge located at the bottom of the Partially
Figure 6
Trim
Front Glass
Log Set
Assembly
3-Position Switch Replacement
CAUTION: If unit was operating prior to servicing allow
at least 10 minutes for lights, heating elements and top
panel to cool off to avoid accidental burning of skin.
WARNING: Disconnect power before attempting any
maintenance to reduce the risk of electric shock or damage
to persons.
Remove the rebox from the mantel.1.
Lay unit on its back.2.
Remove the 12 Philips screws that fasten the bottom 3.
cover to the rest of the rebox. There are: two (2)
screws on each side; two (2) screws on the back panel
(you may have to tip the bottom of the rebox up if it is
laying on its back), four (4) screws in the front directly
under the control panel; and two (2) screws on the
bottom of the rebox (see Figure 8). The bottom panel
is now free to be removed.
Locate the 3-Position Switch mounted on the control 4.
panel on the left side (Figure 9) and disconnect the
three (3) wiring clips noting their original locations.
CAUTION: Internal wire colors may not be the same
within the unit being serviced as those shown. To avoid
damage to the unit, damage to property or personal injury,
ensure wires are reconnected to match their original
locations.
Depress the two (2) retainer clips on the top and 5.
Partially Reective
Glass
Clamp
Figure 7

Dimplex DF2608 Specifications

General

Type	Built-in fireplace
Flueless	Yes
Fuel type	Electric
Orientation	Vertical
Heating power	1440 W
Product color	Black
Fireplace type	Closed

Weight and Dimensions

Depth	224 mm
Width	695 mm
Height	597 mm
