18 www.dimplex.com
Partially Reective Glass Replacement
Tools Required: Phillips Head Screwdriver
Flat Head Screwdriver
CAUTION: If unit was operating prior to servicing allow
at least 10 minutes for heating elements and top panel to
cool o󰀨 to avoid accidental burning of skin.
WARNING: Disconnect power before attempting any
maintenance to reduce the risk of electric shock or damage
to persons.
1. Unplug the unit from power outlet.
2. Remove the rebox from the front of the mantel and
remove front glass assembly (glass lifts o󰀨).
CAUTION: Even though the glass is safety glass it
may break if bumped, struck of dropped. Care must be
taken when handling the glass.
3. Remove the brick panels from either side of the unit,
they are attached using magnets.
4. Gently place the unit its back to expose the bottom
of the unit. Remove the 4 screws from bottom and 2
screw form either side that secure the log set.
5. Lift the log set out of the unit, being careful not to strain
the electronic cords.
6. Locate and remove the 2 brackets that hold the partially
reective glass in the unit (along the bottom). (Figure 7)
7. Gently pry the glass forward using a at head screw-
driver, being careful not to damage the corner tabs.
8. Transfer the rubber corner tabs from the old glass to
the new glass. Properly orient and install the new
glass.
9. Reassemble in the reverse order as above.
Figure 8 Figure 9
Power Regulator Board
Power Regulator Board Installation
(Mod 0 units only)
Tools Required: Phillips Head Screwdriver
Flat Head Screwdriver
CAUTION: If unit was operating prior to servicing allow at
least 10 minutes for heating elements and top panel to cool o󰀨
to avoid accidental burning of skin.
WARNING: Disconnect power before attempting any
maintenance to reduce the risk of electric shock or damage
to persons.
1. Unplug the unit from power outlet.
2. Remove the rebox from the front of the mantel and re-
move front glass assembly (glass lifts o󰀨). Carefully place
the glass assembly aside in a safe location.
CAUTION: Even though the glass is safety glass it may
break if bumped, struck or dropped. Care must be taken when
handling the glass.
3. Remove the loose media from the unit (if applicable).
4. Remove the 14 screws around the back panel of the re-
box and the 3 along the middle of the panel (Figure 2).
5. Locate the main control board. (Figure 2)
6. Remove the two wire connectors that lead to the heater
assembly (the receiver on the control board are labelled as
the “Fan” connections). (Figure 8)
7. Attach the two wire connectors to the power regulator
board.
8. Install the power regulator board to the left connector on
the main control board. (Figure 9)
9. Reassemble the unit.
