signals highlighted on the diagnostics
panel.
13 Secondary telescopic boom lift selector
Not used.
14 Second telescopic boom extension
selector
Not used.
15 Jib levelling selector
To level up jib, turn the selector up,
otherwise, turn it down.
16 Platform rotation selector
To rotate the platform counter clockwise,
turn the selector to the LH.
To rotate the platform clockwise, turn the
selector to the RH.
17 Platform levelling selector
Not used.
