Q
A Load indicator on platform
The yellow indicator lights up to
indicate that the load in the platform
has exceeded the permitted load
when the platform is at the permitted
location.
B Maximum load indicator
The red indicator lights up to indicate
that the load in the platform has
exceeded the maximum permitted
load.
C Generic hazard indicator
The red indicator lights up in hazard
conditions of the truck (together with
the specific signalling) or in case of
mechanical fault of the truck.
In this situation, stop the vehicle after
lowering the platform and check the
signals highlighted on the diagnostics
panel.
D Batteries low voltage indicator light
The red indicator light switches on
when the battery voltage level is
below the threshold allowable for the
correct working of the truck.
In this situation, the operators must
get down and charge it.
If the indicator still lights up after
completing charging it, the battery
should be checked or replaced.
E Front axle wheels alignment
The green indicator light indicates the
alignment of the front axle wheels
with the truck axis.
F Rear axle wheels alignment
The green indicator light indicates the
alignment of the front axle wheels
with the truck axis.
G Turret/telescopic boom alignment
The green indicator light indicates the
alignment of the turret/telescopic
boom with the truck axis.
H Roll-over indicator light
The red light indicates that the
maximum slope with respect to the
horizontal plane of the platform is
reached. The side shift function in one
or both directions will not be
operational.
Only movements for restoring safety
and levelling to the vertical plane are
enabled.
I Fuel level indicator
Not used.
J Spark plugs pre-heating
Not used.
K Engine fault
Not used.
L ELEPHANT drive mode
The green light indicates activation of
the transfer mode for moving over
sloping sections.
M HARE drive mode
The green light indicates activation of
the transfer mode at maximum speed.
N Round steering mode
The green light indicates selection of
steering mode with opposite axles to
reduce the steering radius on the
ground.
O Crab steering mode
