The green light indicates selection of
steering mode with the axles parallel
for lateral movements.
P Differential block
The yellow light indicates activation of
the differential block
Q Digital display
It is used to show the capacity of
battery and code of fault.
6 Differential block
Keeping the selector activated activates
the differential block, increasing the
traction of the wheels on the rear axle
7 Warning buzzer
Use the selector to activate the acoustic
signal.
8 Engine rpm control
Not used.
9 Speed selector
position : low speed,
position : low speed with high
rpm of motor because level
differences are exceeded.
position : high speed.
The movement speed is controlled by the
position of the primary telescopic boom:
high speed can only be used: with controls
from the platform, with boom completely
lowered, retracted and with turret rotation
centred.
As soon as one of the conditions
described above is not respected, the
speed changes automatically to slow.
10 Steering mode selector:
axles with round steering;
only steers the front axle;
axles with parallel steering:
Note: The four wheels should be at original
position before changing the steering
mode.
11 Primary telescopic boom
Not used
12 Lateral movements of the truck
To activate the joystick commands press
the enable pedal on the platform as well
as the enable button present on the front
of the joystick.
To move the truck forwards/backwards,
move the joystick on the vertical axis.
To pilot the steering, act on the selector
provided at the top of the joystick.
13 Primary telescopic boom movement
Move the joystick in both horizontal
directions to extend/retract the primary
boom.
Move the joystick in both vertical
directions to raise/lower the primary
boom.
14 Red emergency stop button
To stop all the functions and switch off the
system, press the red emergency stop
button To activate the machine, set the
red emergency stop button to the ON
position by turning it clockwise
15 Hydraulic generator ( optional)
Not used.
16 Basket signal bypass selector
To enable movements from the control
panel on the platform when something
wrong with the machine happened, keep
the selector enabled together with the
enable key activated and the movement
selectors concerned.
Note: Just when there is some failure
warning except deadly security alarm,
