XKLOADER3/Directed SmartStart, Black 3-pin
connector
Bitwriter PRG1000 XKLoader2XKLoader3
XKL
2
XKL
3
XKLoader3
®
The Black 3-pin port connection is for programming the unit or
when using the optional Directed SmartStart module. When using the
XKLOADER3 and Directechs mobile app, it is possible to configure any
and all of the programmable functions. For more information please
refer to the guide packaged with the XKLOADER3/Directed SmartStart.
