Directed 3305 - Door Lock Harness, White 3-Pin Connector; Control Center

9
© 2019 Directed. All rights reserved.
WIRE
Door Lock Harness, White 3-pin connector
For detailed instructions about connecting to the vehicle’s power
door lock systems, refer to the Door Lock Wiring guide (Tech Tip #
1041) available to authorized dealers under the resource tab at:
www.Directechs.com.
Control Center
The LED and the valet switch are incorporated into the Control Center.
The control center plugs into the 6-pin port on the module with black
RF cable provided.
Valet switch
LED
Control Center
