YELLOW (+) IGNITION INPUT
Connect this wire to the vehicle's (+) 12V ignition wire. This wire is pre-
wired to the starter disable relay and must show (+) 12 volts with the
key in RUN position and during cranking.
10
BROWN (+) SIREN OUTPUT
Connect this to the siren Red wire. Connect the Black wire of the siren to (-)
chassis ground, preferably at the same point you connect the control module’s
Black ground wire.
11
RED (+) 12V CONSTANT POWER INPUT
Before connecting this wire, remove the supplied fuse. Connect to
the battery positive terminal or the constant 12V supply to the ignition
switch.
Note: Always use a fuse within 12 inches of the point you obtain
(+)12V. Do not use the 15 amp fuse in the harness for this purpose. This
fuse protects the control module.
12
RED/WHITE (-) 200mA CHANNEL 2 OUTPUT
When the system receives the code controlling channel 2 for longer
than 1.5 seconds, the RED/WHITE wire will supply an output as long
as the transmission continues. This is often used to operate a trunk/
hatch release or other relay/driven function.
Important: Never use this wire to drive anything but a relay or a low-current in-
put! The transistorized output can only supply 200 mA of current. Connecting
directly to a solenoid, motor, or other high-current device will cause it to fail.
