Table of zones
Zone Trigger type Description
1 Instant Blue wire of the primary 12-pin harness Con-
nect to optional hood/trunk
2 Onboard
shock sensor
Heavy impact detected by the onboard
shock sensor. Armed with bypass notification
3 Two-stage,
Progressive
Door switch circuit. Green or Violet wire of
the primary 12-pin harness warning to full
alarm.
4 Multiplexed
input
BLUE and GREEN wires of optional sensor
plug. Inputs shorter than 0.8 seconds will
trigger a Warn Away response, while inputs
longer than 0.8 seconds will instantly trigger
a full alarm sequence.
5 Two-staged Ignition input. Yellow wire of the primary 12-
pin harness.
Note: The Warn Away response does not report on the LED.
