necting to newer model vehicles use individual door triggers (see Tech
Tip # 1076 for wiring instructions). This wire reports Zone 3.
Note: If using a door trigger wire that has a delay, Menu 2, Feature
# 2-6 or XKLOADER3 can be used to turn door trigger error chirp off.
6
BLUE (-) INSTANT TRIGGER INPUT
This input will respond to a negative input with an instant trigger. It is ideal
for hood and trunk pins and will report on Zone 1. It can also be used
with Directed single-stage sensors. The Blue instant trigger wire can also
be used to shunt sensors during operation of auxiliary channels or remote
start. (See "Bypassing sensor inputs" on page 14 of this guide.)
7
VIOLET (+) DOOR TRIGGER INPUT
Connect the Violet wire to a wire that shows (+)12V when any door is
opened. This wire will report Zone 3. If using a door trigger wire that
has a delay, Menu 2, Feature # 2-6 or XKLOADER3 can be used to
turn door trigger error chirp off.
8
BLACK (-) CHASSIS GROUND
Connect this wire to a clean, paint-free sheet metal location (driver
kick panel). A screw should only be used when in conjunction with
a two-sided lock washer. Under dash brackets and door sheet metal
are not acceptable ground points. It is recommended that all security
components be grounded at the same location.
