Directed DBALL2 User Manual

Platform: DBALL2
Firmware: CHRYSLER Remote Start Ready (RSR) Installation
© 2017 Directed. All rights reserved.
Rev.: 20170214
LED Description Troubleshooting
OBDII feature is not supported.
The diagnostic data bus was not detected, therefore the
SmartStart features will be limited.
Ground When Running (Status) command received. The module has initialized the remote start sequence.
Ignition ON command received.
The module has received the Ignition ON command and
is processing the remote start sequence.
Start ON command received.
The module has received the Start ON command and is
processing the remote start sequence.
PTS shutdown error.
The PTS output from the module was not activated due
to safety protection.
CAN bus incorrectly detected.
Verify the CAN1 and CAN2 connections. Refer to
“Installation (wiring diagrams & vehicle wiring reference
charts)” to check the connections.
LOCK command received.
UNLOCK command received.
TRUNK command received.
AUX1 command received.
AUX2 command received.
AUX3 command received.
Takeover successful. Normal operation.
Runsafe was not disabled.
No UNLOCK command was received prior to opening the
door, or the 45 second timer expired in takeover mode.
Brake was not detected.
The brakes were not detected, which prevents the
system from shutting down the vehicle.
Smart key was not detected.
The smart key was not detected, which prevents the
system from shutting down the vehicle.
Speed was detected.
The vehicle was detected as moving, which prevents the
system from shutting it down.
3x OEM Lock Remote Start Activation was attempted
when RFTD feature is disabled.
Activated from Web automatically when using RSR flash
tool or can be done manually. Refer to feature
programing section for more information.
Feature error.
An RSR feature file mismatch was detected. Please
contact Technical Support.
RSR codes
External module synchronization
Commands
Activation Ground When Running (Status)
If the bypass module fails to flash, it did not receive the
signal. Commands can come from RF or D2D.
Shutdown codes
(Flashes red,
red then
orange) x 10
Flashes red
& orange
Flashes red
x 21
Flashes red
x 2
Flashes red
x 4
Flashes red
x 7
Flashes red
x 9
Flashes red
x 10
Flashes red
x 1
Flashes red
x 3
Flashes
green
Flashes
green
quickly
Flashes
green x 1
Flashes
orange x 1
Flashes
orange x 2
Flashes
orange x 3
Flashes
orange x 5
Flashes
orange x 4
Flashes
orange x 6
Page 31
LED Diagnostics & Troubleshooting
