Directed DBALL2 User Manual

Platform: DBALL2
Firmware: CHRYSLER Remote Start Ready (RSR) Installation
© 2017 Directed. All rights reserved.
Rev.: 20170214
Ignition
Barrel
12-pin Connector
(Vehicle side)
12-pin Connector
(harness side)
12-pin Connector
(harness side)
PU
S
H
TO
RELE
A
SE
Driver
Kick
Panel
(-) Driver Door
Trigger: Violet
Headlight switch
(black 6-pin conn.)
6
5
4
3
2
1
(MUX) Parking Lights: Pin 3
Refer to the Vehicle Wiring Reference Charts for wire color and location.
(MUX) Parking Lights Output: Violet/Green: 8
(MUX) Parking Lights Output: Violet/Brown: 9
(-) RAP Off Output: Yellow/Black: 10
CHTHD1 (R1-R7)
/ THCHD1 (R1)
(optional)
Installation Type 2 - with CHTHD1 (R1-R7) /THCHD1 (R1) T-Harness
Page 6
All connectors are displayed from the wire side (unless specified otherwise).
10
DBALL2
RF
Prog. Button
LED
4
14 12 2
TX
(-) Ground
RX
(+) 12V
6: White/Black: (-) Hood Input
Hood Pin
Remote Start Safety
Override Switch
You can connect to either a XL202
RFTD OR a SmartStart module.
Refer to the SmartStart/XL202
Installation Notes for more information.
