Directed DBALL2 User Manual

Platform: DBALL2
Firmware: CHRYSLER Remote Start Ready (RSR) Installation
© 2017 Directed. All rights reserved.
Rev.: 20170214
Page 5
Type 1 - Vehicle Wiring Reference Chart
Function Color Pin Polarity Location Color Pins
Chrysler Town & Country 2008-2010
HS CAN High White/Lt.Blue 5 Data Wireless Ignition Node on ignition switch. Black 12
HS CAN Low White/Brown 6 Data Wireless Ignition Node on ignition switch. Black 12
Ignition Pink/White 3 (+) Wireless Ignition Node on ignition switch. Black 12
12V Lt.Blue/Red 1 (+) Wireless Ignition Node on ignition switch. Black 12
Ground Black or Black/Striped 4 (-) Wireless Ignition Node on ignition switch. Black 12
Parking Lights White/Brown 1 MUX Headlight switch. Black 10
Driver Door Trigger Violet N/A N/A Drivers kick door harness. N/A N/A
Dodge RAM 1500 /2500/3500 2011-2012
HS CAN High White/Lt.Blue 5 Data Wireless Ignition Node on ignition switch Black 12
HS CAN Low White/Brown 6 Data Wireless Ignition Node on ignition switch. Black 12
Ignition Pink/White 3 (+) Wireless Ignition Node on ignition switch. Black 12
12V Lt.Blue/Red 1 (+) Wireless Ignition Node on ignition switch. Black 12
Ground Black or Black/Striped 4 (-) Wireless Ignition Node on ignition switch. Black 12
Parking Lights White 1 MUX Headlight switch. Black 10
Driver Door Trigger Violet N/A N/A Drivers kick door harness. N/A N/A
Dodge Grand Caravan 2008-2010
HS CAN High White/Lt.Blue 5 Data Wireless Ignition Node on ignition switch. Black 12
HS CAN Low White/Brown 6 Data Wireless Ignition Node on ignition switch. Black 12
Ignition Pink/White 3 (+) Wireless Ignition Node on ignition switch. Black 12
12V Lt.Blue/Red 1 (+) Wireless Ignition Node on ignition switch. Black 12
Ground Black or Black/Striped 4 (-) Wireless Ignition Node on ignition switch. Black 12
Parking Lights White/Brown 1 MUX Headlight switch. Black 10
Driver Door Trigger Violet N/A N/A Drivers kick door harness. N/A N/A
Dodge Journey 2009-2010
HS CAN High White/Lt.Blue 5 Data Wireless Ignition Node on ignition switch. Black 12
HS CAN Low White/Brown 6 Data Wireless Ignition Node on ignition switch. Black 12
Ignition Pink/White 3 (+) Wireless Ignition Node on ignition switch. Black 12
Ground Black or Black/Striped 4 (-) Wireless Ignition Node on ignition switch. Black 12
12V Battery Lt.Blue/Red 1 (+) Wireless Ignition Node on ignition switch. Black 12
Parking Lights White/Violet N/A (+) Drivers kick, harness to rear. N/A N/A
Driver Door Trigger Violet N/A N/A Drivers kick door harness. N/A N/A
Dodge RAM 2009-2010
HS CAN High White/Lt.Green 5 Data Wireless Ignition Node on ignition switch. Black 12
HS CAN Low White/Lt.Blue 6 Data Wireless Ignition Node on ignition switch. Black 12
Ignition Pink/White 3 (+) Wireless Ignition Node on ignition switch Black 12
12V Lt.Blue/Red 1 (+) Wireless Ignition Node on ignition switch. Black 12
Ground Black or Black/Striped 4 (-) Wireless Ignition Node on ignition switch. Black 12
Parking Lights White 1 MUX Headlight switch. Black 10
Driver Door Trigger Violet N/A N/A Drivers kick door harness. N/A N/A
Jeep Grand Cherokee 2011-2013
HS CAN High White/Lt.Blue 5 Data Wireless Ignition Node on ignition switch. Black 12
HS CAN Low White/Brown 6 Data Wireless Ignition Node on ignition switch. Black 12
Ignition Pink/White 3 (+) Wireless Ignition Node on ignition switch. Black 12
12V Red 1 (+) Wireless Ignition Node on ignition switch. Black 12
Ground Black or Black/Striped 4 (-) Wireless Ignition Node on ignition switch. Black 12
Parking Lights White/Lt.Green 1 MUX Headlight switch. Black 10
Driver Door Trigger Violet N/A N/A Drivers kick door harness. N/A N/A
Jeep Grand Cherokee (Smart Key) 2011-2013
HS CAN High White/Black 5 Data Wireless Ignition Node on ignition switch. Black 12
HS CAN Low White/Lt.Blue 6 Data Wireless Ignition Node on ignition switch. Black 12
Ignition Pink/White 3 (+) Wireless Ignition Node on ignition switch. Black 12
12V Red 1 (+) Wireless Ignition Node on ignition switch. Black 12
Ground Black or Black/Striped 4 (-) Wireless Ignition Node on ignition switch. Black 12
Parking Lights White/Green 1 MUX Headlight switch. Black 10
Driver Door Trigger Violet N/A N/A Drivers kick door harness. N/A N/A
Volkswagen Routan 2009-2010
HS CAN High White/Lt.Blue 5 Data Wireless Ignition Node on ignition switch. Black 12
HS CAN Low White/Brown 6 Data Wireless Ignition Node on ignition switch. Black 12
Ignition Pink/White 3 (+) Wireless Ignition Node on ignition switch. Black 12
12V Lt.Blue/Red 1 (+) Wireless Ignition Node on ignition switch. Black 12
Ground Black or Black/Striped 4 (-) Wireless Ignition Node on ignition switch. Black 12
Parking Lights White/Brown 1 MUX Headlight switch. Black 10
Driver Door Trigger Violet N/A N/A Drivers kick door harness. N/A N/A
