Directed DBALL2 User Manual

Platform: DBALL2
Firmware: CHRYSLER Remote Start Ready (RSR) Installation
© 2017 Directed. All rights reserved.
Rev.: 20170214
Ignition
Barrel
HS CAN High:White/Black or White/Lt. Green, pin 5
HS CAN Low: White/Lt. Blue, pin 6
1
6
12
7
(-) Parking Lights Output: Green/Black: 2
HS CAN High: Tan/Black: 3
HS CAN Low: Tan: 4
(+) 12V: Brown: 7
(-) Ground: Black: 14
(+) 12V: Red: 13
Twisted pair at the steering column or behind radio
Ignition Switch
(connector side view)
Ignition Interrupt (vehicle side): Yellow: 8
Ignition Interrupt (conn.side): Orange/Yellow: 9
FT CAN High: Orange/Green: 5
FT CAN Low: Orange/Brown: 6
(+) Ignition: Pink/White, pin 3
(-) Ground: Black/Striped, pin 4
(-) Driver Door
Trigger: Violet
Driver
Kick
Panel
(+) Parking Lights:
White/Violet
(+) 12V:
Red/White
Passenger kick panel, harness to rear
(-) RAP Off Output: Yellow/Black: 10
Refer to the Vehicle Wiring Reference Charts for wire color and location.
White/Orange
White/Gray, White
White/Pink or White Black
CUT
Installation Type 3 - without T-Harness
Page 10
All connectors are displayed from the wire side (unless specified otherwise).
10
DBALL2
Prog. Button
LED
4
14 12 2
RF
TX
(-) Ground
RX
(+) 12V
6: White/Black: (-) Hood Input
Hood Pin
Remote Start Safety
Override Switch
You can connect to either a XL202
RFTD OR a SmartStart module.
Refer to the SmartStart/XL202
Installation Notes for more information.
30
86
85
87
87a
To vehicle’s
(+) Parking Lights
Fuse 15A
+12V
