Type 3 - Vehicle Wiring Reference Chart
Function Color Pin Polarity Location Color Pins
Chrysler 300/300c 2008-2010
HS CAN High White/Black 5 Data Wireless Ignition Node on ignition switch. Black 12
HS CAN Low White/Lt.Blue 6 Data Wireless Ignition Node on ignition switch. Black 12
Ground Black/Striped 4 (-) Wireless Ignition Node on ignition switch. Black 12
Ignition Pink/White 3 (+) Wireless Ignition Node on ignition switch. Black 12
12V Red/White N/A (+) Passenger kick, harness to rear. N/A N/A
Parking Light White/Violet N/A (+) Passenger kick, harness to rear. N/A N/A
FT CAN High White/Orange N/A Data Twisted pair at steering column or behind radio. N/A N/A
FT CAN Low
White/Gray, White or
White/Pink
N/A Data Twisted pair at steering column or behind radio. N/A N/A
Driver Door Trigger Violet 3 (-) Instrument cluster or driver kick. White 26
Dodge Challenger / Challenger (Smart Key) 2008-2014
HS CAN High White/Black 5 Data Wireless Ignition Node on ignition switch. Black 12
HS CAN Low White/Lt.Blue 6 Data Wireless Ignition Node on ignition switch. Black 12
Ground Black or Black/Striped 4 (-) Wireless Ignition Node on ignition switch. Black 12
Ignition Pink/White 3 (+) Wireless Ignition Node on ignition switch. Black 12
12V Red/White N/A (+) Passenger kick, harness to rear. N/A N/A
Parking Lights White/Violet N/A (+) Passenger kick, harness to rear. N/A N/A
FT CAN High White/Orange N/A Data Twisted pair at steering column or behind radio. N/A N/A
FT CAN Low
White/Gray, White or
White/Pink
N/A Data Twisted pair at steering column or behind radio. N/A N/A
Driver Door Trigger Violet 3 (-) Instrument cluster or driver kick. White 26
Dodge Charger 2008-2010
HS CAN High White/Black 5 Data Wireless Ignition Node on ignition switch. Black 12
HS CAN Low White/Lt.Blue 6 Data Wireless Ignition Node on ignition switch. Black 12
Ground Black/Striped 4 (-) Wireless Ignition Node on ignition switch. Black 12
Ignition Pink/White 3 (+) Wireless Ignition Node on ignition switch. Black 12
12V Red/White N/A (+) Passenger kick, harness to rear. N/A N/A
Parking Light White/Violet N/A (+) Passenger kick, harness to rear. N/A N/A
FT CAN High White/Orange N/A Data Twisted pair at steering column or behind radio. N/A N/A
FT CAN Low
White/Gray, White or
White/Pink
N/A Data Twisted pair at steering column or behind radio. N/A N/A
Driver Door Trigger Violet 3 (-) Instrument cluster or driver kick. White 26
Dodge Magnum 2008
HS CAN High White/Black 5 Data Wireless Ignition Node on ignition switch. Black 12
HS CAN Low White/Lt.Blue 6 Data Wireless Ignition Node on ignition switch. Black 12
Ground Black/Striped 4 (-) Wireless Ignition Node on ignition switch. Black 12
Ignition Pink/White 3 (+) Wireless Ignition Node on ignition switch. Black 12
12V Red/White N/A (+) Passenger kick, harness to rear. N/A N/A
Parking Lights White/Violet N/A (+) Passenger kick, harness to rear. N/A N/A
FT CAN High White/Orange N/A Data Twisted pair at steering column or behind radio. N/A N/A
FT CAN Low
White/Gray, White or
White/Pink
N/A Data Twisted pair at steering column or behind radio. N/A N/A
Driver Door Trigger Violet 3 (-) Instrument cluster or driver kick. White 26
