Directed DBALL2 User Manual

Platform: DBALL2
Firmware: CHRYSLER Remote Start Ready (RSR) Installation
© 2017 Directed. All rights reserved.
Rev.: 20170214
FT CAN High: Tan/Black: 3
(+) Ignition Output: Yellow: 8
FT CAN Low: Tan: 4
FT CAN Low: Pin 7
FT CAN High: Pin 6
1 8
Sentry Key Module
(black 8-pin conn.)
(-) Ground: Black: 14
(+) 12V: Red: 13
(MUX) Ign.Output: Violet/Green: 8
(MUX) Ign. Output: Violet/Brown: 9
(-) RAP Off Output: Yellow/Black: 10
(-) Pk. Lights Output: Green/Black: 2
(+) Ignition Input: Brown: 7
30
86
85
87
87a
To vehicle’s
(+) Parking Lights
Fuse 15A
+12V
(+) Ignition:Pink or
Pink/Striped, pin 3
MUX: Violet/Brown, pin 1
(+) 12V: Red or
Red/Striped,
pin 5
(-) Ground: Black or
Black/Striped, pin 4
Drivers or passenger kick
harness to rear
(+) Parking Lights
White/ Violet
Refer to the Vehicle Wiring Reference Charts for wire color and location.
(+) 12V
Refer to the Vehicle
wiring reference chart.
Driver Door Trigger
Refer to the Vehicle
wiring reference chart.
Installation Type 6 - without T-Harness
Page 20
All connectors are displayed from the wire side (unless specified otherwise).
10
DBALL2
Prog. Button
LED
4
14 12 2
RF
TX
(-) Ground
RX
(+) 12V
6: White/Black: (-) Hood Input
Hood Pin
Remote Start Safety
Override Switch
You can connect to either a XL202
RFTD OR a SmartStart module.
Refer to the SmartStart/XL202
Installation Notes for more information.
If the vehicles
security light
remains ON after
performing a
remote start
takeover,
disconnect the
Violet/Brown
MUX connection.
