Wire Information Connector Information
Function Color Pin Polarity Location Color Pins Ref.
Ford Flex 2009-2010
RX Violet/Gray 4 Data (PATS) connector. Black 4 A
TX Yellow/Orange 3 Data (PATS) connector. Black 4 A
12V Blue/Red 4 (+) Ignition switch. Black 7 B
Starter Blue/White 7 (+) Ignition switch. Black 7 B
Ignition White/Orange 1 (+) Ignition switch. Black 7 B
Accessory Violet/Green 6 (+) Ignition switch. Black 7 B
Parking Lights Violet/White 6 (+) SJB (Smart Junction Box) passenger side of the center console. Gray 13 G
HS CAN High White/Blue 6 Data OBDII. Black 16 C
HS CAN Low White 14 Data OBDII. Black 16 C
MS CAN High Gray/Orange 3 Data OBDII. Black 16 C
MS CAN Low Violet/Orange 11 Data OBDII. Black 16 F
Driver Door Trigger Green/Violet 14 Cut SJB passenger side of the center console. Gray 26 F
Trunk/Hatch Release Brown 7 (+) SJB passenger side of the center console. Gray 26 F
Lock Blue/Green 17 (-) SJB passenger side of the center console. Gray 26 F
Unlock Yellow/Violet 4 (-) SJB passenger side of the center console. Gray 26 F
Factory Alarm Disarm Green/Violet 8 (-) SJB passenger side of the center console. Gray 26 F
Tach Green/Blue, Gray/
Yellow, Violet/Gray,
Yellow/Orange,
Brown, Green/White
1 (AC) Any fuel injector. N/A 2 N/A
Ford Focus 2008
RX Yellow/Orange 4 Data (PATS) connector. Black 4 A
TX Violet/Gray 3 Data (PATS) connector. Black 4 A
12V Blue/Red 4 (+) Ignition switch. Black 7 B
Starter Blue/White 7 (+) Ignition switch. Black 7 B
Ignition Gray/Violet 1 (+) Ignition switch. Black 7 B
Accessory Violet/Green 6 (+) Ignition switch. Black 7 B
Parking Lights Violet/White 6 (+) SJB (Smart Junction Box) under drivers dash. Gray 13 E
HS CAN High White/Blue 6 Data OBDII. Black 16 C
HS CAN Low White 14 Data OBDII. Black 16 C
MS CAN High Gray/Orange 3 Data OBDII. Black 16 C
MS CAN Low Violet/Orange 11 Data OBDII. Black 16 C
Driver Door Trigger Green/Violet 14 Cut SJB (Smart Junction Box) under drivers dash. Gray 26 D
Trunk/Hatch Release Brown 20 (-) SJB under drivers dash. Gray 26 D
Lock Blue/Green 17 (-) SJB under drivers dash. Gray 26 D
Unlock Yellow/Violet 4 (-) SJB under drivers dash. Gray 26 D
Factory Alarm Disarm Violet/Brown 8 (-) SJB under drivers dash. Gray 26 D
Tach Green/Blue, Gray/
Yellow, Violet/Gray,
Yellow/Orange
1 (AC) Any fuel injector. Black 2 N/A
