Pre-installation and application warnings
START HERE
This section highlights important information for this specific firmware and will assist in pricing accordingly, as
well as bringing awareness to any operational or vehicle limitations.
Compatibilities and Requirements
T-Harness
compatible
THTON7
Keys required for
programming
1
Keys required
for operation
0
Vehicle Takeover
Refer to the Quick Reference Guide section for more details.
Firmware notes
 Keysense: Ensure you do not connect the keysense wire in the installation for each of these vehicles or you will encounter issues when
attempting to start the vehicle.
 Security-Only: When flashing Security Only with a THTON7 T-Harness, configure relay 3 to "starter kill".
 T-Harness (THTON7):
•All T-Harness wires not listed in the diagram are not required for the installation. Loose wires such as Siren Output and
Hood Input may need to be pulled from the tapped section of the T-harness. Refer to the "wiring diagram with T-Harness"
for more information on connections and installation instructions.
•The optional Plug & Play THTON7 T-Harness is sold separately.
•The OBDII Diagnostic Connector features will remain the same even when the T-Harness is installed.
•All T-Harness wires not listed in the diagram are not required for the installation.
 Fuses: It is important to check that the fuses are positioned correctly in the module. Proper fuse positioning is displayed on each wiring
diagram.Unless specified otherwise, all connectors are displayed from the wire side, with the exception of the OBDII diagnostic
connector.
 Refer to the "Vehicle connections" following the installation diagram.
Footnotes
[1] Hood pin: The installation of an aftermarket hood pin is only required on vehicles that are not equipped with a factory
hood pin, or if not supported in data
[2] Siren: The siren is only required when enabling the security features during module flashing.
[3] Security-only: Refer to the "Locating components in the vehicle" section for optional starter disable connection
information.
[4] Autolight Interrupt: Connection only required if the vehicle is equipped with automatic headlights.
[5] TPMS: Depending on the vehicle's trim, the TPMS Ignition Interrupt connection may be required to obtain OEM remote
functionality during runtime. Note: the TPMS light may flash during runtime.
