Wire Information Connector Information
Function Color Pin Polarity Location Color Pins Ref.
Mercury Mountaineer 2008-2010
RX Violet/Gray 4 Data (PATS) connector. Black 4 A
TX Yellow/Orange 3 Data (PATS) connector. Black 4 A
12V Violet/Red 4 (+) Ignition switch. Black 7 B
Starter Blue/White 7 (+) Ignition switch. Black 7 B
Ignition White/Orange 1 (+) Ignition switch. Black 7 B
Accessory Violet/Green 6 (+) Ignition switch. Black 7 B
Keysense Blue/Gray 5 (+) Ignition switch. Black 7 B
HS CAN High White/Blue 6 Data OBDII. Black 16 C
HS CAN Low White 14 Data OBDII. Black 16 C
MS CAN High Gray/Orange 3 Data OBDII. Black 16 C
MS CAN Low Violet/Orange 11 Data OBDII. Black 16 C
Parking Lights Blue/White 11 (+) Fuse/SJB (Smart Junction Box) under
drivers dash.
Brown 32 G
Driver Door Trigger Green/Violet 17 Cut Fuse/SJB under drivers dash. Black 32 H
Lock Gray/Yellow 27 (-) Fuse/SJB under drivers dash. Black 32 H
Unlock Violet/Gray 26 (-) Fuse/SJB under drivers dash. Black 32 H
Trunk/Hatch Release Brown 29 (-) Fuse/SJB under drivers dash. Black 32 H
Tach NOT Violet N/A (AC) Any fuel injector. N/A N/A N/A
