18
DS4+ FORD6
© 2017-12-13 Directed. All rights reserved.
Wire Information Connector Information
Function Color Pin Polarity Location Color Pins Ref.
Ford Taurus 2013-2014
RX Violet/Gray 4 Data (PATS) connector. Black 4 A
TX Yellow/Orange 3 Data (PATS) connector. Black 4 A
Trunk/Hatch Release Brown or Brown/Yellow 2 (-) Trunk release switch. Black 2 F
Starter Blue/White 7 (+) Ignition switch. Black 7 B
Ignition White/Orange 1 (+) Ignition switch. Black 7 B
Accessory Violet/Green 6 (+) Ignition switch. Black 7 B
Keysense Blue/Gray 5 (+) Ignition switch. Black 7 B
Parking Lights Yellow/Blue 6 (+) BCM (Body Control Module) under drivers
dash.
Gray 10 H
HS CAN High White/Blue 6 Data OBDII. Black 16 C
HS CAN Low White 14 Data OBDII. Black 16 C
MS CAN High Gray/Orange 3 Data OBDII. Black 16 C
MS CAN Low Violet/Orange 11 Data OBDII. Black 16 C
Driver Door Trigger Green/Violet 9 Cut BCM under drivers dash. Black 26 G
Lock Blue/Green 6 (-) BCM under drivers dash. Black 26 G
Unlock Yellow/Violet 8 (-) BCM under drivers dash. Black 26 G
12V Red 6 (+) BCM under drivers dash. White 32 H
Tach Green/Blue, Gray/Yellow,
Violet/Gray, Yellow/
Orange, Brown, Green/
White
1 (AC) Any fuel injector. White 2 N/A
Ford Transit Connect (with power locks) 2010-2013
RX White/Lt. Green 4 Data (PATS) connector. Black 4 A
TX Gray/Orange 3 Data (PATS) connector. Black 4 A
12V Red 4 (+) Ignition switch. Black 7 B
Starter Gray/Black or Orange/
Black
7 (+) Ignition switch. Black 7 B
Ignition Green/Yellow 1 (+) Ignition switch. Black 7 B
Accessory Yellow 6 (+) Ignition switch. Black 7 B
Keysense Black/Red 5 (+) Ignition switch. Black 7 B
Parking Lights Orange/Yellow 13 (+) Headlight switch. Black 16 F
HS CAN High Gray/Red 6 Data OBDII. Black 16 C
HS CAN Low Blue/Red 14 Data OBDII. Black 16 C
MS CAN High Gray/Orange 3 Data OBDII. Black 16 C
MS CAN Low Blue/Black 11 Data OBDII. Black 16 C
Driver Door Trigger Black/Yellow 18 (-) GEM (Generic Electronic Module) behind
dash fuse box.
Gray 23 G
Lock Black/Orange 10 (-) GEM behind dash fuse box. Green 23 H
Unlock Black/Green 11 (-) GEM behind dash fuse box. Green 23 H
Tach Green/Blue, Gray/Yellow,
Violet/Gray, Yellow/
Orange
1 (AC) Any fuel injector. Black 2 N/A
