Directed DIRECTWIRE DIRECTECHS 933.TL14 User Manual

31
DS4+ FORD6
© 2017-12-13 Directed. All rights reserved.
Type 3
Refer to "Pre-installation and application warnings" on page 4 for important information, such as the description of each special note referenced in the diagram ( ).
Ignition
Switch
(gray conn.
at ign. switch)
6 1087 9
1 532 4
16
8
9
1
(+) 12V Input: Blue/Red: 2
(+) Ignition Output: Blue: 3
MS CAN Low: Tan: 1
(-) Power Liftgate Output: Red/White: 4
MS CAN High: Tan/Black: 2
HS CAN High: Orange/Green: 4
HS CAN Low: Orange/Brown: 3
Data RX: Orange/Black: 7
(+) Parking Light Output: White: 5 & 11
HS CAN Low: Pin 14
HS CAN High: Pin 6
MS CAN Low:
Pin 11
MS CAN High:
Pin 3
Refer to the Vehicle wiring
reference charts for wire and
connector details related to
the standard connections in
the vehicle.
Data TX: Yellow/Black: 8
(-) Lock Output: Dk. Green/Black: 3
(+) Accessory/Keysense Output: White: 7
(+) Starter Output: Violet/Black: 8
(-) Unlock Output: Dk. Blue/Black: 9
P.A.T.S. - 4-pin
(at ignition switch)
1
2
3
4
RX: Pin 4
TX: Pin 3
22 810 12
4 2442
DS4+
DS4
Slide
to open
Proper Fuse
Positioning
DS4+ DS4
It is important to check that the
fuses are positioned correctly.
MAIN (5A) (+)
(-) RLY3 PK LIGHT (15A) (+)
(-) ACC & START (30A) (+)
(-) FLEX RLY (20A) (+)
IGN (20A) (+)
MAIN (5A) (+)
(-) RLY3/PK LIGHT(15A) (+)
5
30
20
20
5
15
15
(+) 12V: Pin 9
(+) Start: Pin 10
(+) Ignition: Pin 1
(+) Keysense: Pin 3
(+) Accessory: Pin 7
6A Diode
(-) Ground: Black: 10
Driver Door Trigger
RAP Off Interrupt: Lt. Green: 8
RAP Off Interrupt: Lt. Green/White: 9
Cut
(+) 12V Input: Red: 6 & 12
Hood
Pin
(-) Hood Pin Input: Gray: 21
(AC) Tach Output: Violet/White: 22
Siren
(+) Siren Output: Brown/Red: 11
OBDII Diagnostic
(connector side view)
