Directed DS3 User Manual

34
DS4+ FORD6
© 2017-12-13 Directed. All rights reserved.
Wire Information Connector Information
Function Color Pin Polarity Location Color Pins Ref.
Ford F450 2008-2010
RX Violet/Gray 4 Data (PATS) connector. Black 4 A
TX Yellow/Orange 3 Data (PATS) connector. Black 4 A
12V Blue/Red or White/
Violet
9 (+) Ignition switch. Gray 10 B
Starter Blue/White 10 (+) Ignition switch. Gray 10 B
Ignition White/Orange 1 (+) Ignition switch. Gray 10 B
Accessory Brown/Yellow or
Yellow/Orange
7 (+) Ignition switch. Gray 10 B
Keysense Blue/Gray 3 (+) Ignition switch. Gray 10 B
Parking Lights Violet/White 6 (+) SJB (Smart Junction Box) passenger kick panel. Gray 13 E
HS CAN High White/Lt. Green or
White/Blue
6 Data OBDII. Black 16 C
HS CAN Low Pink/Lt. Green or
White
14 Data OBDII. Black 16 C
MS CAN High Gray/Orange 3 Data OBDII. Black 16 C
MS CAN Low Violet/Orange 11 Data OBDII. Black 16 C
Driver Door Trigger Green/Violet 14 Cut SJB passenger kick panel. Gray 26 D
Lock Blue/Green 17 (-) SJB passenger kick panel. Gray 26 D
Unlock Yellow/Violet 4 (-) SJB passenger kick panel. Gray 26 D
Tach Blue N/A (AC) Customer Access Harness behind data link connector. N/A N/A N/A
Lincoln Navigator 2008-2014
RX Yellow/Orange or
Blue/Gray
4 Data (PATS) connector. Black 4 A
TX Violet/Gray or Violet/
Brown
3 Data (PATS) connector. Black 4 A
Power Liftgate Gray/Yellow 5 (-) Power liftgate switch. Black 6 F
12V Blue/Red 9 (+) Ignition switch. Gray 10 B
Starter Blue/White 10 (+) Ignition switch. Gray 10 B
Ignition White/Orange 1 (+) Ignition switch. Gray 10 B
Accessory Brown/Yellow 7 (+) Ignition switch. Gray 10 B
Keysense Blue/Gray 3 (+) Ignition switch. Gray 10 B
Parking Lights Violet/White 6 (+) SJB (Smart Junction Box) in passenger kick panel. Gray 13 E
HS CAN High White/Blue 6 Data OBDII. Black 16 C
HS CAN Low White 14 Data OBDII. Black 16 C
MS CAN High Gray/Orange 3 Data OBDII. Black 16 C
MS CAN Low Violet/Orange 11 Data OBDII. Black 16 C
Driver Door Trigger Green/Violet 14 Cut SJB in passenger kick panel. Gray 26 D
Lock White/Brown 17 (-) SJB in passenger kick panel. Gray 26 D
Unlock Blue/Brown 4 (-) SJB in passenger kick panel. Gray 26 D
Tach NOT B lue N/A (AC) Any fuel injector. N/A N/A N/A
