1592022760 Quick reference guide iCHILL 200CX EVO rel. 1.0 15/40
• press the UP or DOWN button to select the submenu;
• press the SET to enter the submenu.
Exit menu functions:
• Press the menu button or wait the time-out.
Entering the menu, it is possbile to:
1. Read and reset the alarms (ALrM)
2. Read and reset the alarm log (ALOG)
3. Upload the parameter into the Hot Key (UPL)
4. Enable – disable a gas circuit (CrEn)
5. Enable – disable a compressors (COEn)
6. Read and reset the number of compressor running hour (Hour)
7. Read and reset the number of compressor starts-up (COSn)
8. Read dynamic set point probe value (PbdS)
9. Read compressor discharge temperature (COdt)
10. Read condensing fan speed percentage of the proportional output (Cond)
11. Read the percentage of the proportional output 0 ÷ 10 Vdc Pout
12. Enable – disable one of the pumps POEn
13. Read the delay time between two defrost cycles (dF)
14. Read auxiliary output probe value (uS)
15. Read the temperature measured by internal sensor of the remote keyboards (trEM)
16. Read the temperature, the set point and the output status of the Free cooling (FC)
17. Read the temperature, the set point and the output status of the Solar panel (SoL)
18. Read temperature, pressure and status of the electronic expansion valve 1 (Et1)
19. Read temperature, pressure and status of the electronic expansion valve 2 (Et2)
11.1 ALARM LIST: READ AND RESET
ALrM FUNCTION
1. Push MENU key
2. The display shows AlrM label
3. Push SET key (Nothing happens if there are not alarms)
4. The bottom display shows the alarm code and the top display shows the label rSt, if it is possible
to reset the alarm, or NO if it is not possible to reset the alarm
5. Push UP or DOWN to scroll the alarm list (if more than one alarm is active)
6. Repeat the reset procedure for each alarm
7. To exit the ALrM reset, push MENU or wait the timeout.
11.2 ALARM LOG LIST
ALOG FUNCTION
1. Push MENU key
2. Push UP or DOWN to select ALOG
3. Push SET key
4. The bottom display shows the alarm label, the top display shows a number in the range 00 to 99.
5. Use the UP or DOWN keys to scroll the list.
6. To exit the ALOG function push MENU or wait the timeout.
