1592022760 Quick reference guide iCHILL 200CX EVO rel. 1.0 17/40
dP06..dP09
• the load status
Compressor/s
(blinking during the start up
delay)
Economy function
/
Water pump / Supply fan
Unloading function
Condenser fan
Economy or ON/OFF by
timetable
Electric heater
Defrost
Sanitary water
Alarm
Recovery enabled
Meaning of the keys:
Allows to read the value of the
probes configured in the Ichill
Allows to read/modify the set point
Allows to switch on the Ichill in
heating or cooling mode (see
parameter CF78)
Allows to read the alarms
Allows to switch on the Ichill in
heating or cooling mode (see
parameter CF78)
Allows to enter the SERVICE
menù
Allows to put the Ichill in STD-BY
Allows to read the main
information of the circuits
(compressor status, water pump
status, pressure probe value,…)
Note:
in case of alarm, press any key to silence the buzzer.
