dji Inspire 2 Series User Manual

26
©
2018 DJI All Rights Reserved.
INSPIRE 2 SERIES User Manual
The aircraft cannot detect objects in shadow. Fly carefully.
Ultrasonic sensor detection range is as follows.
5. Place the side of visual calibration plate with the dots facing the forward vision system, and follow
the instructions in the DJI Assistant 2 to complete calibration.
6. Place the aircraft straight, and ensure the dotted side of the visual calibration plate faces the
downward vision system. Follow the instructions in the DJI Assistant 2 to complete calibration.
Calibration
Forward and Downward Vision Systems cameras installed on the aircraft are calibrated on delivery.
However these cameras are vulnerable to excessive impact and will require occasional calibration
via DJI Assistant 2.
Calibration via the Visual Calibration Plate
1. Ensure the aircraft is in landing mode. Power on the Intelligent Flight Battery and toggle the USB
Mode Switch down.
2. Connect the Inspire 2 and the PC via a USB cable with Double A ports.
3. Launch DJI Assistant 2 and login with a DJI account.
4. Click Inspire 2 and the calibration button.

dji Inspire 2 Series Specifications

General

Battery Capacity	4280 mAh
Battery Voltage	22.8 V
Operating Temperature	-20°C to 40°C
Camera Compatibility	Zenmuse X7, Zenmuse X5S, Zenmuse X4S
Transmission Distance	7 km (FCC), 4 km (CE)
Max Ascent Speed	5 m/s
Max Descent Speed	4 m/s
Operating Frequency	2.4 GHz and 5.8 GHz
Gimbal	3-axis
Satellite Systems	GPS/GLONASS
Charging Temperature Range	5°C to 40°C
Live View Quality	1080p
Max Tilt Angle	35°
Transmitter Power (EIRP)	26 dBm (FCC), 20 dBm (CE)
Video Transmission System	DJI Lightbridge
