dji Inspire 2 Series User Manual

©
2018 DJI All Rights Reserved.
37
INSPIRE 2 SERIES User Manual
Power Outlet
Controlling Camera
Shoot videos or images and adjust camera settings via the Shutter Button, Camera Settings Dial
Video Recording Button and Gimbal Dial on the remote control.
[1] Camera Settings Dial
Turn the dial to adjust camera settings such as ISO, shutter speed, and aperture without letting
go of the remote controller. Press down on the dial to toggle between these settings.
[2] Shutter Button
Press to take a photo. If burst mode is activated, multiple photos will be taken with a continuous
press. Press to take a photo even when recording.
[3] Video Recoding Button
Press once to start recording video, then press again to stop recording.
[4] Gimbal Dial
Control the tilt of the gimbal.
Controlling Aircraft
This section explains how to use the various features of the remote controller. The Remote Controller
is set to Mode 2 by default.
Stick Neutral/ mid point: Control sticks of the Remote Controller are placed at the central
position.
Move the Stick: The control stick is pushed away from the central position.
Charging Remote Controller
Charge the remote controller via supplied charger.
[
1
]
[
2
]
[
3
]
[
4
]
B
B

dji Inspire 2 Series Specifications

General

Battery Capacity	4280 mAh
Battery Voltage	22.8 V
Operating Temperature	-20°C to 40°C
Camera Compatibility	Zenmuse X7, Zenmuse X5S, Zenmuse X4S
Transmission Distance	7 km (FCC), 4 km (CE)
Max Ascent Speed	5 m/s
Max Descent Speed	4 m/s
Operating Frequency	2.4 GHz and 5.8 GHz
Gimbal	3-axis
Satellite Systems	GPS/GLONASS
Charging Temperature Range	5°C to 40°C
Live View Quality	1080p
Max Tilt Angle	35°
Transmitter Power (EIRP)	26 dBm (FCC), 20 dBm (CE)
Video Transmission System	DJI Lightbridge
